Processing width (mm):

10–160

Processing thickness (mm):

3–100 (single-piece thickness range)

Front worktable length (mm):

2500 (conveyor)

Feeding speed (m/min):

6–36 (steplessly adjustable)

Spindle diameter (mm):

。40

Spindle speed (r/min):

6500

Air source pressure (MPa):

0.6

First lower shaft motor power (kW):

4 (optional dovetail, trapezoidal,r    angular)

Right vertical shaft motor power

(kW):

4

Left vertical shaft motor power (kW):

4

First upper shaft motor power (kW):

5.5

Second upper shaft motor power

(kW):

/

Second lower shaft motor power

(kW):

4

Beam lifting motor power (kW):

0.55

Feeding motor power (kW):

3

Total power (kW):

26.55

First lower shaft tool diameter (mm):

。125 (optional dovetail, trapezoidal, rectangular, multiple support strips)

Right vertical shaft tool diameter

(mm):

。125–。160

Left vertical shaft tool diameter (mm):

。125–。160

First upper shaft tool diameter (mm):

。125–。160

Second upper shaft tool diameter (mm):

/

Second lower shaft tool diameter (mm):

。125–。180

Feeding wheel diameter (mm):

。140

Dust suction pipe diameter (mm):

。140
